Warman Pump

M, AH, HH series centrifugal slurry pumps adopt replaceable wear-resistant metal or rubber liners. The impellers are made of wear-resistant metal or rubber. The pumps are mainly used to pump high-hardness, strong-corrosion and high-concentration liquids that contain suspended solid particles, such as finished ores, refuse ores, ashes, cinders, cements, mud, mineral stones etc.

Pošaljite upit

Download

Warman pump

image001(001)

M, AH, HH series slurry pump

Brief Introduction

Meaning of pump model

Pump 4/3 A -AH (or M、HH)

AH (or M、HH)----Pump type

A----Frame type

3--- Outlet diameter (inch)

4----Inlet diameter (inch)

Main Technical Parameters

Model	Allowable max. power of motor Kw	Material		Clear water performance						Impeller
		liner	Impeller	Clear water performance		Head m	Speed r/min	Max eff %	NPSH m	Qty	Dia. mm
				m³/h	l/h
2/1½B-AH	15	M	M	32.4-72	9-20	6-58	1200-3200	45	3.5-8	5	184
		RU	RU	25.2-54	7-15	5.5-41	1000-2600	50	2.5-5		178
3/2C-AH	30	M	M	39.6-86.4	11-24	12-64	1300-2700	55	4-6	5	214
		RU	RU	36-75.6	10-21	13-39	1300-2100		2-4		213
4/3C-AH	30	RU	RU	79.2-180	22-50	5-34.5	800-1800	59	3-5	5	245
4/3D-AH	60
4/3C-AH	30	M	M	97.2-194.4	27-54	9-53	1000-2200	55		3	240
4/3D-AH	60
4/3E-HH	120	M	M	126-252	35-70	12-97	600-1400	50	2-5	5	508
6/4D-AH	60	M	M	180-396	50-110	7-61	600-1600	55	3-8	4	372
6/4E-AH	120
6/4D-AH	60	RU	RU	144-324	40-90	12-45	800-1350	65	3-5	5	365
6/4E-AH	120
8/6E-AH	120	M	M	360-828	100-230	10-61	500-1140	72	2-9	5	510
8/6R-AH	300
8/6E-AH	120	RU	RU	360-828	100-230	7-52	400-1000	70	2.5-6	4	536
8/6R-AH	300
8/6T-HH	1200	M	M	576-1152	160-320	32-95	450-725	65	6-10	5	965
